CONTENTS
4 force screws:
M10 x 1.5 - M12 x 1.5 - M14 x 1.5 - M16 x 1.5 mm, 450 mm long
Plates and Sleeves can also be used in a standard workshop press
Sleeve wall thickness: 5 mm
Sleeve height: 94 mm
Sleeve outer diameter: 44, 46, 48, 50, 52, 54, 56, 58, 60, 62, 64, 66, 68, 70, 72, 74, 76, 78, 80, 82 mm
End Plates : Ø 83 x 20 mm
USE
A Spindle with Nut
B End Plates
C Sleeves
D Housing (Bearings / Bushes)
E Wheel Bearing / Bushes
A
C
D
E
B
C
B
