USE
To adjust the camshaft, the ruler is inserted into the
groove at the end of the camshaft and the ruler is
supported on the sealing surface of the camshaft
housing.
Turn the motor in the normal direction of rotation until
the tool can be inserted into the groove of the camshaft.
Turn the crankshaft slowly in the normal direction of
rotation until the hole in the toothed belt wheel are
aligned with the hole in the engine.
Insert the locking pin through the hole in the timing belt
pulley into the engine housing bore.
