BH FITNESS T1 BASIC - ASSEMBLY INSTRUCTIONS; PARTS LIST AND ASSEMBLY DIAGRAM

SECTION 2
ASSEMBLY INSTRUCTIONS
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
A Computer Console 1 a Allen Bolt M8xP1.25x15 10
B Main Frame 1 b Washer Ø8xØ16x1.5t 10
C Upright (L) 1 c Allen Bolt M8xP1.25x60 2
D Upright (R) 1 d Screw M5xP0.8x10 4
E Handrail Protecting Cover 2 e Allen Key 5mm (70mmx70mm) 1
F Decorative Cover (L) 1 f Allen Key 6mm (80mmx80mm) 1
G Decorative Cover (R) 1 g Safety Key/Clip 1
H Bottle 1 h SILICON 1
i Allen Bolt M8xP1.25x50 2
f
abc d
A
B
C
D
E
F
G
e
g
h
H
