Biasi Riva Plus - Technical Information

Riva Plus Manual
9
The Riva Plus is a high efficiency condensing, wall mounted gas boiler which provides central
heat. The boiler features a gas valve which modulates the energy input from
49476 BTU/h to 116008 BTU/h. The boiler is shipped fully assembled with the components
listed on page 11. All units are pressure and combustion tested at the factory prior to
shipping.
Key Features:
• Wall mountable - saving valuable
floor space.
• Several flue options available
• Electronic spark ignition
• Safety flow switch - positioned on
the main circuit, which monitors the
flow and protects the main heat
exchanger from thermal shock
should there be a lack of water in
the system.
• Frost protection - contains an
integral frost protection system to
prevent frost damage which can
occur in areas susceptible to very
cold weather conditions.
• Boiler operation recognition system
- should the boiler not be used for
longer than 24 hours, it then
performs a controlled system test
to ensuring the motorized
components within the boiler do not
become inoperable due to lack of
use.
• Gas valve modulation - the gas
input modulates based off central
heating temperature to within ± 2 ºF
• Diagnostic information system
equipped with three LED diagnostic
lights for quick error assessment
GENERAL
Height in
31.6
Width in
15.8
Depth in
13.8
Weight lb
98.1
CENTRAL HEATING
Maximum working temp. °F
185
Temp. Regulation range* °F
100-176
Maximum pressure psi
30.0
Minimum pressure psi
4.35
Max head loss (at 4.4 GPM) ft
8.3
*At the minimum useful output
1. Gene
ral Information
2. Technical Information (M135.30CR)
