1.3.4 Type code
The type references, when combined, consti-
tute the type code of the unit's modules, for
instance:
PS B-20-H1-M
PS P-21
PS G-40
PS V-61-H1C3-I
Various combinations can be made.
Explanation of type code
series
PS
modular fan
coil unit
module
B, P, F, FP,
L, G, V, VE
see Section
1.3.3
capacity
20, 21, 40,
41, 60, 61
H1, H2,
H3, H4
water heating
C3, C4
water cooling
H1C3,
H2C2
water heating
and cooling
with base
module and/or
heating module:
heating and/or
cooling
HE
electric heating
M
modulating
control
S
speed control
I
Interface, either
with or without
touch control
B
Basic, without
control
with base
module:
electronic
control
without
reference
not described
in this manual
1.3.5 Type plate
The type plate is located on the base mod-
ule.
Type PS B-40-H2-M
Code U 230 V ~ 50 Hz
Biddle bv
Markowei 4
NL-9288 HA Kootstertille
Nº 123456/1-1 07-12 I
max
L1 0.88 A
I
max
L2 -
M 51 kg I
max
L3 -
Medium LPHW P
motor
0.20 kW
p
max
600 kPa P
heating
-
4023
Example of a type plate
References on the type plate
Type
full type code of unit
Code
if applicable:
unit code of electronic control
M
weight of unit
P
max
with water heating:
maximum allowable operating
pressure
U
supply voltage
I
max
maximum amperage
P
motor
maximum power absorbed by fans
P
heating
with electric heating:
maximum power absorbed by heat-
ing
1.4 Components
1.4.1 Required components
The following components are delivered
separately but are always required:
- mounting kit, consisting of a suspension
rail and fasteners for linking modules
- electronic control system components,
such as a controller, control cables, etc.
(see the documentation of the control
system)
