Disassembly
5
1. Remove the power plug
from the outlet.
6. Connect the water feed
pipe that was removed
when the bidet was
installed.
7. Open the water feed
valve by turning it
counter-clockwise.
Be sure of no leakage
around the water feed
connection.
8. Attach to the toilet the
seat and cover that were
removed when the bidet
was installed.
2. Close the water feed
valve by turning it
clockwise.
Completely drain out the toilet water
tank, release the nuts at bidet body of
the bidet hose, and then remove them
from the main body.
2. Press the release button
on the side of bidet.
Completely drain the water from the
water tank. After draining the water
thoroughly, pull the main body forward,
and then remove it from the toilet.
5. Remove bidet hose,
toilet-use hose & T-valve.
4. Unscrew the metal
bolts, and remove the
toilet brackets. Once
removed, pull out the
rubber nuts.
Top mount metal bolt
Bracket Holder
Catch Plate
Top Mount Rubber Nut
To Next Page
