Bieffe EMILIO BF089E - Page 43

EMILIO
43
ENGLISH
1 Safety plug/discharge valve 10B Container for water/detergent supply
2 Inox body 13 Steam outlet
3 Steam generator 14 Vacuum opening
4 Body/base hooks 15 Main switch
5 Vacuum motor 16 Switch for the rst heang element
6 Motor/body hooks 17 Switch for the second heang element
7A Vacuum power plug 18 Power supply cable
7B Vacuum power in-let 19 Switch of the vacuum motor
8 Electric socket of the vacuum motor 20 Steam ready indicator
9 Plasc container for boiler water 21 No water indicator
9B Container for water supply 22 An-dust lter
10 Plasc container for water/detergent
MODEL EMILIO RA - EMILIO RA PLUS - EMILIO RA PLUS CAR
5
19
7A
14
2
3
4
6
C
A
B
10
10B
9
9B
18
8
15 16 17
13
20 21
7B
1
22
