2.16 Logic card of ICON3000
The connector is made of two pieces, header and crimp housing. The header is welded
on the printed circuit board, the crimp housing is connected to wires. Due to mechanical
block, to disconnect the crimp housing from header can be difcult and could damage
connector or wires.
Figure 15
Terminal
Board
Power Card
Position
encoder
Local
controls
Motor
temperature
Speed
sensor
To Next Page
