Black: Battery –
Yellow: UART- SEND (TXD)
Green: UART-RECEIVE (RXD)
10AUTO SLEEP AFTER 5 MINUTES
When the riding speed is 0 km/h for 5 minutes, the system will go to
sleep automatically.
INSTALLATION INSTRUCTION
The instrument is fixed on the handlebar, adjust the appropriate
perspective, and the button is arranged on the easy control position. In the
case of power failure, the corresponding connector and connector
controller instrument for inserting installation can be completed.
Attentions! Install the instrument from right to left and avoid stretching
buckle over angle.
Step1: Make the snap ring buckle into the handelbar in direction of
the arrow.
Step2: make the instrument slip insert the snap ring from right to
left.
