battery is severely low and needs to be recharged immediately.
Low battery flash
13CABLE DEFINITION
1 Red： Battery +
2 Blue： Weak lock
3 Black： Battery-
4 Green: UART-RECEIVE (RXD)
5 White: UART- SEND (TXD)
14AUTO SLEEP AFTER 5 MINUTES
When the riding speed is 0 km/h for 5 minutes, the system will go to
sleep automatically.
PREPARATION BEFORE OPEN THE
POWER
Ensure that the connectors are better joined and open the power
supply of the e-bike.
INSTALLATION INSTRUCTION
The instrument is fixed on the handlebar, adjust the appropriate
