NORMAL OPERATION
1ON/OFF
Hold ON/OFF and start the display. The display will provide power
for the controller. Hold ON/OFF again can open the backlight. With
display on, press ON/OFF for 3 seconds to turn off the power. With the
display off, there is no battery consumption. The leakage current is no
more than 2 µA.
※ The panel will go to sleep when speed is 0 km/h for 5 minutes.
2CURRENT DISPLAY
That represents the discharging current of the controller currently, each
segment is 2A, six segments is >=12A.
3 SPEED DISPLAY
It displays the current riding speed of e-bike. The speed display is as
below.
