means auto cycle display.
11
、
BATTERY INDICATOR
When the battery capacity is high, the six battery segments are all light.
When the battery is low, the battery frame will flash. It indicates that the
battery is severely low and needs to be recharged immediately.
Low battery flash
12
、
CABLE DEFINITION
1 Red： Battery +
2 Blue： Weak lock
3 Black： Battery-
4 Green: UART-RECEIVE (RXD)
5 White: UART- SEND (TXD)
