Billion BiPAC 8501 R3 User Manual

Billion BiPAC 8501 R3/ 8521 R3 SHDSL.bis Firewall Bridge/Router
5
The Front LEDs of BiPAC 8521 R3
The Rear Ports of BiPAC 8501 R3
LED Status Meaning
Red Boot failure or in emergency mode
1 Power
Green System ready
Green Transmission speed at 10/100Mbps
2
Ethernet 1 ~ 4
(EWAN - LAN 4)
Blinking Data being transmitted/received
Green Blinking DSL synchronizing or waiting for DSL synchronizing
Green Successfully connected to an SHDSL DSLAM (Line Sync).
3 DSL 1 ~ 2
Off DSL cable unplugged
Green Router is IP connected and data is transmitting
Red Router is not IP connected or in Bridge mode
4 Internet
Off SHDSL connection not present.
1
2
3
4
1
2
4
5
3

Billion BiPAC 8501 R3 Specifications

General

Brand	Billion
Model	BiPAC 8501 R3
Category	Network Router
Language	English
