S30 x 6
Fit the Opening Window
close to the top edge
of the window frame
Fixing Opening Window
Fix the Window Rebate
to the side of the inside
of Window frame
PP x 12
WR
x 2
x 2
481mm
895mm
Fix the Window Rebate
to the side of the inside
of Window frame
PP x 8
WR
x 2
x 2
481mm
480mm
Darcy
Door Fixing Stage
Riley
S30 x 18
H03
x 6
S30 x 6 CS x 1
7KH&DVHPHQW6WD\MRLQWȴWV
centrally to the opening window.
2 people will be required for this.
Fixing Opening Window
43
46
47 48
44 45
