Billyoh INS-0042 - Assembly - Roof Structure; Truss and Roof Panel Positioning; Securing Wall Panels to Floor

For Queries and Help please call Product Support:
01636 858 377
S50
x 6
S50
Screw the Wall
3DQHOVWRWKHȵRRU
The distance 879mm
or 1172mm is the
width of a Roof Sheet.
Measure from the
framing to the
centre of the Truss
Truss Position Diagram
Side View
879mm or 1172mm
Position the Roof Panel
square with the framing
S70 x 10
7KH5RRI3DQHOVKRXOGȴWKDOI
ZD\DFURVVWKH5RRI7UXVV
The Roof
Panel should
PDWFh Whe
Side Panel
widWh.
Side View
Correct Position
Side View
Incorrect Position
Roof Panel Position
Line up the Roof Panel with
the framing not the cladding
25
28
29 30
26 27
