Billyoh INS-0042 - Assembly - Door Hardware and Finishing; Installing Door Lock and Rebate; Applying Door Cloaking Strip

For Queries and Help please call Product Support:
01636 858 377
Fix the Door Rebate to
the side of the frames
on each side
PP x 16
DR
DR
x 2
x 2
1558mm
1859mm
S30 x 4
S25 x 12
x 2
x 2
100mm
Top
Bottom
S25 x 4
Align Door Lock Handle over
the key hole on the inside of
0DLQ'RRU7KHORFNȴWVFHQWUDOO\
to the frame.
Fixing the Door Lock Handle
x 1
Cloaking Strip Fixing Stage
N40
Cut to size
CSP
2100mm
N40
CSP
2100mm
Cut to size
Fix the
Door Cloaking
Strip to the door.
S30 x 4
CSP
x 1
1850mm
49
52
53 54
50 51
