Cloaking Strip Fixing Stage
N40
Cut to size
CSP
2100mm
N40
CSP
2100mm
Cut to size
Fix the
Door Cloaking
Strip to the door.
S30 x 4
CSP
x 1
1850mm
Felt Fixing Stage
Length of
roof + 140mm
x 4
Front View
(10ft Gables)
(4 PIECES OF FELT)
Felt
Felt
Felt
Felt
T10
Tack to hold
in place
70mm overhang at
each end
Fold over
Eaves
S50 x 16
1610mm
x 4
Facia Block Fixing Stage
55
58
59 60
56 57
