4.1 LCD Screen Back Light
Every time a button is pressed (except PTT button), the LCD
Screen back light will illuminate for 4 seconds.
4.2 Power Saving
Your PMR unit has special circuitry designed to extend the
life of your battery. When the unit is not used for 4 seconds,
it will automatically switch into a low power mode.
The Power Saving feature does not affect the PMR’s ability to
receive transmissions. When a signal is detected, it
automatically returns to full power mode.
4.3 Battery Meter Indicator
The PMR can detect the battery charge levels. The Battery
icon will display the battery charge status as follows;
Battery charge at high level.
Battery charge at empty level. The empty battery symbol
will blink, then unit emits 3 "beep" tones and will
automatically shuts down.
Important: Replace the Batteries. Use only Alkaline
“AAA” 1.2V batteries.
4. Auxiliary Features
0 Range (Km) 3
Signal Strenght
Range Slope
Optimum (open area) (1)
Medium ground based
obstruction (2)
Heavily built up area (3)
The Transmission range of the product is dependent on the environment
terrain where it is being used, the following diagram attempts to guide
the user on the sort of performance to expect for everyday use.
Range Check
The Transmission range will be affected as shown in the above diagram.
The transmitting range typical values for different environment conditions
will be (1) 3 km (2) 1.5 km (3) 750m. It should be remembered that
these are only guide values as actual achieved distances will be
dependent on the environment and terrrain.
5. Effective Range
Binatone Help Line - 0845 345 9677
6. Specifications
8 Channels
0.5W
Up to 3 Kms. (2 Miles)
Channels A
va
ilable
Output Power (TX)
Range
