FLUID SECTION SERVICE KITS

862020 Diaphragms Kits include: Items 7 and 8 Diaphragms, plus “O” ring items: 2, 3, 19 and Key-Lube grease packet.
□
862025 Ball and Seat Repair Kits include:
(standard stainless steel ball and seat)
◆
862026 Ball and Seat Repair Kits include:
(optional PTFE ball and stainless steel seat)
WETTED COMMON PARTS
ALUMINUM
818820, 818821
STAINLESS STEEL
818822, 818823
Item Description (Size) Qty
Part No. [Mtl] Part No. [Mtl]
1
Rod
(1)
873005 [C] 873005 [C]

2 ‘‘O” Ring
(3/32” x 3/4” OD)
(1) [B] [B]

3 ‘‘O” Ring
(1/16” x 5/8” OD)
(4) [T] [T]

5 Washer - Air Side
(3 - 5/8" OD)
(2) 873638 [C] 873638 [C]

6 Washer - Fluid Side
(3 - 5/8" OD)
(2) 873283 [SS] 873283 [SS]

7 Diaphragm (2) [T] [T]

8 Diaphragm (2) [SP] [Sp]
9 Washer
(0.505” ID)
(2) 873262 [SS] 873262 [SS]
14 Screw
(1/2 - 20 x1”)
(2) [SS] [SS]
15 Fluid Cap (2) 873285 [A] 873628 [SS]
16
Manifold
(N.P.T.F. -1 threads)
(2) 873021 [A] - - - - - -
Manifold
(B.S.P. threads)
(2) 873022 [A] - - - - - -
◆

19 ‘‘O” Ring
(3/32” x 1-9/16” OD)
(4) [T] [T]
◆

21 Seat (4) [SS] [SS]
◆

22
Ball
(1” dia.)
(4) [SS] [SS]
Ball
(1” dia.)
(4) [T] [T]
26 Bolt
(5/16” - 18 x 1”)
(8) [SS] [SS]
29 Nut
(5/16” - 18)
(16) [SS] [SS]
43 Ground Lug
(see page 7)
(1) [Co] [Co]
57 Ground Kit Assembly
(not shown)
(1) 873067 - - - 873067 - - -
60
Inlet Manifold
(N.P.T.F. -1 threads)
(1) - - - - - - 873631 [SS]
(B.S.P. threads)
(1) - - - - - - 873632 [SS]
61
Outlet Manifold
(N.P.T.F. -1 threads)
(1) - - - - - - 873629 [SS]
(B.S.P. threads)
(1) - - - - - - 873630 [SS]

”Smart parts”, Keep these items on hand in addition to the service kits for fast repair and reduction of down time.
PARTS LIST /81882X FLUID SECTION
MATERIAL CODE
[A] = Aluminum
[B] = Nitrile
[C] = Carbon Steel
[Co] = Copper
[Sp] = Santoprene
[SS] = Stainless Steel
[T] = PTFE
Items # 19 21 22
Qty 4 4 4
Items # 19 21 22
Qty 4 4 4
