3.1.3 Side Panels
On RS123w and RS123w-4G Devices, two 3G/4G antenna connectors are located on the side panels, one on each
side:
Fig. 6: Side panels
The connectors are as follows:
Side panels connectors
Item Description
12 WWAN 3G/4G MAIN and AUX antenna connectors. Only RS123w-4G Devices
3.1.4 Underside Panel
The following elements can be found on the underside panel:
Fig. 7: Underside panel
The following table contains details on the significant elements on the underside panel:
Underside panel elements table
Item Description
A Rubber feet.
B Holes for wall mounting.
C Internal module SIM tray.
bintec elmeg
3 Components and Power Supply
RS123 Router 9
