A.6.7 USB Interface
3G USB MODEMS Please see the bintec website http://www.bintec-elmeg.com to get a list of the sup-
ported 3G USB modems.
SPEED The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
CONNECTOR USB Type A.
A.6.8 Configuration Interface
MODE 115200-8-N-1 without flow control.
CONNECTOR USB Type B
A.6.9 Power Supply
INPUT VOLTAGE 110 - 240 VAC
FREQUENCY 50 - 60 Hz
INPUT CURRENT 0.7 A
CONNECTOR IEC C6
A.6.10 Dimensions and weight
TYPE Metallic housing with optional mounting in a 19 inches rack (bracket option).
LENGTH x WIDTH x HEIGHT 265mm x 170mm x 40mm
WEIGHT 1.4 kg.
A.6.11 Environmental Specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 40 ºC
STORED: -25 ºC to 70 ºC
RELATIVE HUMIDITY On: 10 % to 90 %, non-condensing
bintec elmeg
Technical Information
RS123 Router 29
