Q&A-Installation
BIOCOOL ESTANDARD COOLERS
Communication errors in installation
• Why did not detect some coolers?
1. Review location of connection of BioCool Standard control and connected
coolers
2. Make sure you have good contact with the RJ wiring -electronic tab HUBB
3. By using the crimper : CAUTION! Because if we press a lot you can join
wiring and lose communication .
4. Make use of an accessory such as a flange for pressure connection RJ with
electronic tab HUBB ensuring a good connection.
5. To ensure it is resolved and there is good communication, see BioCool
control in the solid line in the right corner that it is fixed.Otherwise,
change the HUBB.
Electric installation errors
• What is the wiring recomended in the power supply of the cooler?
The electrical wiring must be protected on electric tray.In other case can be
installed follow the UNE 21123 UNE designation W - K 0.6 / 1 kW with flexible
conductor.
NEVER! Place the communication cable and power supply in the same tray
MODELO
TIPO DE CABLE ELECTRICO
BIO-18D
3 x2,5 mm
2
de sección(I
max
=10 A)
BIO-30D
Cable trifasico (N+3F+Tierra)
Q&A-Installation
• Should I put some kind of protection??
In the case BIOCOOL coolers , it is recommended to place each evaporative
cooler to a circuit breaker box distribution board or general stress. One general
low-tension should have the MCB’s with In> =1,25 x Iprevista contemplated by
the UNE 20460-4-43.
Water installation
• What PH should I use?
PH between -.
• What water main should I use to pipe water supply ?
We recommend using pipe polietilieno to hold well pressure ( 8-10 kg / cm2).
NEVER use a drainage pipe as it cannot withstand sufficient pressure
• Can I make the water supply from a tank ? And the water treatment?
Yes, if the supply is made from a tank , it is recommended that the pressure at
the end of the line installation is 1.5-3 kg / cm2 .. In addition , you must perform
maintenance on the valves cleaning the grids of these for cases with water
with gravel.
• ¿How many valves should be placed?
Se recomienda una llave de paso de cada equipo y luego una general, además
de una llave de paso para desagüe. See previous scheme.
