5400230 Rev. H
Dimensions
Charging Station (W X D X H) 4.7” X 4.0” X 2.8” / 11.9 cm X 10.2 cm X 7.1 cm
iLase Handpiece with surgical tip and battery
attached (Length X Diameter)
8.1” X 0.75” / 20.5 cm X 1.90 cm
1.77” X 2.36” X 2.26” / 4.5 cm X 6.0 cm X 6.0 cm
Weight
iLase Complete System 1.89 lbs / 0.86 kg
iLase Charging Station 0.87 lbs / 0.34 kg
iLase with Battery attached 0.22 lbs / 0.10 kg
iLase Charging Station PowerSupply and cord/plug
set
0.62 lbs / 0.28 kg
Electrical
Voltage (to power supply) 90 – 230 VAC
Amperage (max) 0.8A
Frequency 50 – 60 Hz
Electrostatic Discharge Immunity Up to 10 KV (per IEC 60601)
Battery Lithium ion 3.7 V 800 mAh
Recharge Time (fully discharged) 2 hours
Safety
Discharge over current sensor and resettable circuit
breaker
Laser
Laser Class IV (4)
Wavelength 940 nm ± 10nm
Output Power 3.0 W Max CW / 5.0 W Peak Power (Pulse Mode)
Power Accuracy ± 20%
Pulse Duration Continuous | 0.1 ms | 1 ms
Pulse Interval -------------- | 0.2 ms | 1 ms
Aiming Beam Laser diode, max 1 mW, 625-670nm, Class 1
N.O.H.D. 2.61 meters
Environmental
Temperature - Operating 68° – 77° F (20° – 25° C)
Temperature - Storage 59° – 90° F (15° – 35° C)
Humidity - Operating 15 – 95 % non-condensing
Humidity - Storage 10 – 70 % non-condensing
Altitude - Operating maximum 10,000 ft (3048 m)
Altitude - Storage maximum 12,000 ft (3658 m)
