BIOS Diagnostics PROTOCOL 7D MII BD250 - Interpreting Results and Clearing Data; Blood Pressure Assessment Indicator Guide; Clearing Measurement Memory

Press the “MEM“ button to display the subsequent measurements.
B. If the Protocol was done incorrectly or if any measurements were missed, the monitor will display “ ”
then “ ” then the average measurement and then display the subsequent measurements.
Reasons why the Protocol Software is displaying :
- Not enough measurements have been saved in memory. For the Protocol Software to work there needs to be
28 measurements saved in memory, 4 measurements taken for 7 days.
3.10ClearMeasurementsFromMemory
If you are sure that you want to permanently remove all stored memories, first choose the mode you want to delete
the memory from, then press the SET button 9 times until“ ”appears when the power is off. Press the ST
button until “ ”flashes 3 times to clear the memory. After this, press the “MEM”button, the symbols“ ”
and“ ”will appear on the screen. This means that the memory has successfully cleared.
3.11BloodPressureAssessmentIndicator
The bars on the left hand side of the display show you the range within which the indicated blood pressure
values lies. Depending on the height of the bar, the readout value is either within the normal (green), borderline
(yellow) or danger (red) range.
The classification is based on standards adopted by Hypertension Canada.
The indicator bar rises according to your measurement.
•Ifyourmeasurementhasonlyoneortwobars,your
measurement is in the green zone, or “Normal”.
•Ifyourmeasurementhasthreebars,itisintheyellowzone,or
“High Normal”.
•Ifyourmeasurementhasfourbars,itisintheredzone“High
Blood Pressure with Self / Home Monitoring”.
•Ifyourmeasurementhasvebars,itisintheredzoneor
“Moderate to Severe Hypertension”.
SYS
145
135-145
95
85-95
80-84
71-80
70
121-134
110-120
110
(mmHg)
DIA
Red
Red
Yellow
Green
Green
