5.5.3. Orbital + Reciprocal + Vibro
Set the speed (1-100 rpm) and time
(1 - 250 sec) of Orbital rotation.
Set the angle (1-90º) and time (1 -
250 sec) for Reciprocal motion. Set
the turning angle (0-5º) and time (1 - 5
sec) for Vibro motion.
Note that if the set time of Reciprocal motion is shorter or equal to the set
time of Vibro motion then the Reciprocal motion will be omitted (Orbital +
Vibro).
5.5.4.Orbital + Reciprocal + Pause
Set the speed (1-100 rpm) and time (1 -
250 sec) of Orbital rotation. Set the
turning angle (1-90º) and time (1 - 250
sec) for Reciprocal motion. Set the
angle of Vibro motion mode to zero.
Set the time for Vibro/pause mode (1 -
5 sec), which is the time of pause
duration.
Note that if the set time of Reciprocal motion is shorter or equal to the set
time of Vibro/pause mode, the Reciprocal motion mode will be omitted
(Orbital + Pause).
5.5.5.Reciprocal Rotation
Set the speed (1-100 rpm) for Orbital
rotation. Set time for Orbital rotation to
zero (OFF). Set the turning angle (1 -
90º) and time (1 - 250 sec) of
Reciprocal motion. Set the time for
Vibro motion to zero (OFF).
5.5.6. Reciprocal + Pause
Set the speed (1-100 rpm) of Orbital
rotation. Set time of Orbital rotation to
zero (OFF). Set the angle (1-90º) and
time (1 - 250 sec) of Reciprocal
motion. Set the time for vibro motion
o
0
o
1-90
1-250 1-250
1-5
Time (sec.)
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
o
1-90
o
0-5
OFF OFF1-250
Time (sec.)
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
1-5
1-250
o
1-90
o
0
OFF
Time (sec.)
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
1-100
1-100
1-100
o
1-90
1-250 1-250
1-5
o
1-5
Time (sec.)
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
1-100
