Page 8
stopped with hand during operation, the program does not stop and the
platform motion is automatically resumed after the platform is released.
4.10.Disconnect the external power supply unit from electric circuit to turn off
the unit.
5. Program setting
When setting program parameters please mind that the unit may be
unable to operate properly in reciprocal and vibration modes with
maximum load. The recommended load is indicated in table 1 on page12.
5.1. Press the Select key (Fig.1/1) to choose the parameter to change (the
active parameter is flashing).
5.2. Use the q and p keys (Fig.1/4) to set the necessary value (note: if the key
is pressed for more that 2 sec the numerical changes quickly).
5.3. Saving the program doesn`t require additional operations: the
microprocessor saves the last parameter changes as the working
program automatically.
5.4. The countdown timer is used to control the operation time. The timer can
be set for the period from 1 min to 24 hours.
5.5. The examples below show separate motion types and their available
combinations in cycles. The data to the right show the possible parameter
values for each type.
5.5.1. Orbital Rotation
Set the speed of Orbital rotation (1-
100 rpm), time of Orbital rotation (1 -
250 sec) and time for Reciprocal
motion to zero (OFF).
5.5.2. Orbital + Reciprocal Rotation
Set the speed (1-100 rpm) and time
(1 - 250 sec) of Orbital rotation. Set
the turning angle from vertical plane
(1-90º) and time (1 - 250 sec) for
Reciprocal motion. Switch off the
Vibro motion (set the time of Vibro
motion to 0 (OFF)).
Time (sec.)
o
1-90
o
0-5
1-250 OFF
OFF
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
o
1-90
o
1-5
1-250 1-250
OFF
Time (sec.)
Orbital
(rpm)
Reciprocal
(deg.)
Vibro
/ pause
1-100
1-100
To Next Page
