1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Pentium 4 / Pentium D /
Celeron D / Celeron 4xx processor up to 3.8
GHz *It is recommended to use processors
with 95W power consumption.
Supports Hyper-Threading
Execute Disable Bit
Enhanced Intel Sp eedStep
Extended Memory 64 Technology
FSB 533 / 800 / 1066 / 1333 MHz
Chipset
Intel 945GC
Inte l ICH7
Graphics Intel GMA 950 Max Shared Video Memory is 224MB
Super I/O
ITE IT8712F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
H/W Monitor
Fan Speed Contro ller
ITE's "Smart Guard ian" funct ion
Main
Memory
DIMM Slots x 2
Each DIMM supports 256/512MB & 1GB
DDR2
Max Memory Capacity 2GB
Supports DDR2 400 / 533 / 667
Dual Channel Mode DDR2 memory modu le
Registered DIMM and ECC DIMM is not supported
IDE Integr ated IDE Contro lle r
Ultra DMA 33 / 66 / 100 Bus Master Mode
supports PIO Mode 0~4,
SATA Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spec if icat ion co mp liant.
LAN Atheros L2
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High-Definition Audio support
PCI Express x16 slot x1 Supports PCI-E x16 expansion cards
PCI Express x1 slot x1 Supports PCI-E x1 expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
Printer Port Connector x1 Each connector supports 1 Printer port
On Board
Connector
SATA Connector x4 Each connector supports 1 SATA devices
