Chapter 1: Introducon | 5
A68N-2100E / A68N-2100K / A68N-2100X / A68N-5600E
1.4 Rear Panel Connectors
Note
 
»
HDMI/VGAoutputrequireanAMDfamilyprocessorwithintedratedgraphics.
 
»
SincetheaudiochipsupportsHighDenionAudioSpecicaon,thefunconofeachaudiojack
canbedenedbysoware.Theinput/outputfunconofeachaudiojacklistedaboverepresents
thedefaultseng.However,whenconnecngexternalmicrophonetotheaudioport,pleaseuse
theLineIn(Blue)andMicIn(Pink)audiojack.
 
»
Maximumresoluon
HDMI:4096x2160@24Hz,compliantwithHDMI1.4
VGA:1920x1200@60Hz
 
»
WhenusingthefrontHDaudiojackandplugintheheadset,therearsoundwillbeautomacally
Disabled.
