Chapter 2: Hardware installaon | 9
Step 4: Hold the CPU down rmly, and then close the lever to locked the posion
Note
» 
»
Please turn o the Power Supply before remove the CPU socket.
2.2 Install a Heatsink
<TypeA>
Step 1: Place the heatsink and fan assembly onto the retenon frame. Match the heatsink clip
with the socket mounng-lug. Hook the spring clip to the mounng-lug.
Step 2: On the other side, push the retenon clip straight down to lock into the plasc lug on
the retenon frame, and then press down the locker unl it stops.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar B450MHP and is the answer not in the manual?

Biostar B450MHP Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetAMD B450
SocketAM4
Memory Slots2 x DIMM
Max Memory32GB
PCIe Slots1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
Storage4 x SATA III, 1 x M.2
LANRealtek RTL8111H
Video Outputs1 x HDMI
Memory SpeedDDR4 3200+(OC)/ 2933/ 2667/ 2400/ 2133 MHz
