22 | 第三章: UEFI BIOS和軟體
3.3 軟體
安裝軟體
1. 將光碟放入光碟機，若Autorun功能已啓動，則會顯示驅動安裝程式。
2. 選擇Software Installation，然後點擊各軟體圖示。
3. 根據螢幕上的指令完成安裝。
啓動軟體
安裝程式完成後，桌面上將出現軟體圖示。請雙擊圖示啓動軟體工具。
»
所有軟體的相關訊息和内容若有變更，恕不另行通知。為使系統性能更佳，軟體會不斷升級。
»
下面的圖片和訊息僅供參考，此主板的實際訊息和設定可能與手册略有差異。
BIOScreen 工具
此實用工具可以將開機畫面個性化。您可以選擇BMP格式來自定義電腦開機畫面。
請參照以下步驟來更新開機畫面：
• 載入圖片(Load Image)：選擇圖片作為開機畫面。
• 轉換(Transform)：轉換圖片並預覽。
• 更新BIOS(Update Bios)：將圖片寫入BIOS記憶體，然後完成更新。

Biostar B450MX-S Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD B450
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2933, 3200, 3600, 4000, 4066, 4133, 4200, 4266, 4333 MHz
RAID levels	0, 1, 10
RAID support	Yes
Supported storage drive types	HDD
Supported storage drive interfaces	M.2, SATA III
DirectX version	12.0
Parallel processing technology support	-
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI

Weight and Dimensions

Width	244 mm
