1.4 Rear Panel Connectors
B450MX
B450MX-S
Note

»
B450MX:DVI-D/VGA/HDMIoutputrequireanAMDfamilyprocessorwithintegratedgraphics.
B450MX-S:HDMIoutputrequireanAMDfamilyprocessorwithintegratedgraphics.

»
SincetheaudiochipsupportsHighDenionAudioSpecicaon,thefunconofeachaudiojack
canbedenedbysoware.Theinput/outputfunconofeachaudiojacklistedaboverepresents
thedefaultseng.However,whenconnecngexternalmicrophonetotheaudioport,pleaseuse
theLineIn(Blue)andMicIn(Pink)audiojack.

»
Maximumresoluon
DVI-D:1920x1200@60Hz
VGA:1920x1200@60Hz
HDMI:4096x2160@30Hz,compliantwithHDMI1.4

»
TheAthlon200GECPUwillnotsupportVGAPortsignals.

»
WhenusingthefrontHDaudiojackandplugintheheadset,therearsoundwillbeautomacally
Disabled.
