Biostar B550MH 3.0 User Manual

Chapter 2: Hardware installaon | 9
B550MH 3.0
Step 4: Hold the CPU down rmly, and then close the lever to locked the posion
Note
»
»
Please turn o the Power Supply before remove the CPU socket.
2.2 Install a Heatsink
<TypeA>
Step 1: Place the heatsink and fan assembly onto the retenon frame. Match the heatsink clip
with the socket mounng-lug. Hook the spring clip to the mounng-lug.
Step 2: On the other side, push the retenon clip straight down to lock into the plasc lug on
the retenon frame, and then press down the locker unl it stops.

Biostar B550MH 3.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD B550
Socket	AM4
Maximum Memory	64GB
LAN	Realtek RTL8111H Gigabit LAN
PCIe Slots	1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
Storage Interface	4 x SATA III
USB Ports	4 x USB 3.2 Gen1 (2 front, 2 rear), 2 x USB 2.0 (2 rear), 2 x USB 2.0 (Front)
Audio	Realtek ALC887 7.1-Channel
Video Outputs	HDMI, DVI-D
Memory Slots	2 x DIMM
