Biostar B660GTN User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 12th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/Intel®
Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® B660
Memory
Supports Dual Channel DDR4-4500+(OC)/4333(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/
3733(OC)/3600(OC)/3200/3000/2933/2800/2666/2400/2133
2x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/ 8/ 16/ 32GB DDR4 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 2x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s) : Supports AHCI & Intel® Rapid Storage Technology
1x M.2 (M Key) Socket (M2_PCIEG4_64G):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD
1x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD & SATA III (6Gb/s) SSD
Supports Intel® Rapid Storage Technology and Intel® Optane Technology
LAN
Realtek RTL8125B
10/ 100/ 1000/ 2500 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC1220
7.1 Channels, High Denion Audio, Hi-Fi(Front + Rear)
USB
2x USB 3.2 (Gen1) port (2 via internal header)
4x USB 3.2 (Gen2) port (4 on rear I/Os)
4x USB 2.0 port (2 on rear I/Os and 2 via internal header)
Expansion Slots 1x PCIe 5.0 x16 Slot
Rear I/Os
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI Port
1x DP Port
4x USB 3.2 (Gen2) Port
2x USB 2.0 port
3x Audio Jack
Internal I/Os
4x SATA III Connector (6Gb/s)
1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel® CNVi
1x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x CPU water cooling connector (CPU_OPT)
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Switch Buon
1x LED Header (5V)
1x LED Header (12V)
* M.2 (E key) Wi-Fi card is not provided
Form Factor Mini-ITX, 170 X 170mm
OS Support
Windows 10(64bit) / Windows 11(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.
