Biostar B660GTQ User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 12th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® B660
Memory
Supports Dual Channel DDR4 2933/3200/3600(OC)/3800(OC)/4000(OC)/4133(OC)/4300(OC)/5000+(OC)
4x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 2x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 (M Key) Socket (M2_PCIEG4_64G):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD
1x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):
Supports M.2 Type 2242/ 2260/ 2280/ 22110 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD & SATA lll (6Gb/s)SSD
LAN
Realtek RTL8125B
10/ 100/ 1000/ 2500 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC1220
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
2x USB 3.2 (Gen2) Type-C port (1 on rear I/O and 1 via internal headers)
5x USB 3.2 (Gen2) port (5 on rear I/Os)
2x USB 3.2(Gen1) port (2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 3.0 x1 Slot
1x PCIe 5.0 x16 Slot (x16 mode)
1x PCIe 3.0 x16 Slot (x4 mode)
Rear I/Os
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI Port (HDMI2.0)
1x DP Port
1x DVI-D Port
1x USB 3.2 (Gen2) Type-C Port
5x USB 3.2 (Gen2) Port
2x USB 2.0 port
1x LAN port
3x Audio Jack

»
ConnuedonNextPage
