G31D-M7 BIOS Manual
27
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
South Bridge Chipset Configuratio n
USB 2.0 Controller [E nabled]
Audio Controller [A zalia]
Onboard Lan Control [E nabled]
Onboard Lan Boot ROM [D isabled]
SMBUS Controller [E nabled]
SLP_S4# Min. Assertion Width [1 to 2 seconds]
USB Functions [8 USB Ports]
MAC ID Information
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
USB Functions
The item determines the number of functional USB port.
Options: 8 USB Ports (Default) / 6 USB Ports / 4 USB Ports / 2 USB Ports /
Disabled
USB 2.0 Controller
This entry is to enabled/ disabled EHCI controller only. This Bios itself may/may not
have high speed USB support. If the Bios has high speed USB support built in,the
support will be automately turn on when high speed device were attached.
Options: Enabled (Default) / Disabled
Audio Controller
This item allows you to select the Audio support.
Options: Azalia (Default) / All Disabled

Biostar G31D-M7 Specifications

General

Form Factor	Micro ATX
CPU Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	4GB
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA 3100
Video Outputs	1 x VGA
Chipset	Intel G31
Memory Standard	DDR2 667/800
Expansion Slots	1 x PCI Express x16, 2 x PCI
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8102EL 10/100 Mbps
USB Ports	4 x USB 2.0 (Rear)
Power Connector	24-pin ATX
