G31D-M7 BIOS Manual
29
6 Performance Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chips et Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Advance Performance Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
CPU Frequency Setting [333]
PCIE Clock By [Auto]
CPU Voltage [Default]
FSB Voltage [Default]
Memory Voltage [Default]
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
DRAM CAS# Latency [5]
DRAM RAS# to CAS# Delay [6 DRAM Clocks]
DRAM RAS# Precharge [6 DRAM Clocks]
DRAM RAS# Activate to Precha [15 DRAM Clocks]
PCIE Frequency Setting [100]
Exit
Allows BIOS to Select
CPU Over Clock.
Note:
MIN = 100 MHZ
MAX = 800 MHZ
CPU Frequency Setting
This item allows you to select the CPU Frequency.
Options: 333 (Default) / Min= 100MHz; Max= 800MHz
PCIE Clock By
This item allows you to select the PCIE clock control
Options: Auto (Default) / Manual
PCIE Frequency Setting
This item allows you to select the PCIE clock control
Options: 100 (Default) / Min=100; Max=150
