Page #31 background imageLoading...
Page #31 background image
G31D-M7 BIOS Manual
30
CPU Voltage
This item allows you to select CPU Voltage Control.
Options: Default (Default) / +5% / +10% / +15%
FS B Voltage
This item allows you to select FSB Voltage Control.
Options: Default (Default) / +0.1V / +0.2V / +0.3V
Memory Voltage
This item allows you to select Memory Voltage Control.
Options: Default (Default) / +0.1V / +0.2V / +0.3V / +0.4V / +0.5V / +0.6V /
+0.7V
DRAM Frequency
This item allows you to control the Memory Clock.
Options: Auto (Default) / DDR2 533Mhz / DDR2 667Mhz / DDR2 800Mhz
Configure DRAM Timing by SPD
Options: Enabled (Default) / Disabled
DRAM CAS# Latency
Options: 5 (Default) / 3 / 4 / 6
DRAM RAS# to CAS# Delay
Options: 6 DRAM Clocks (Default) / 3 DRAM Clocks / 4 DRAM Clocks /
5 DRAM Clocks
DRAM RAS# Precharge
Options: 6 DRAM Clocks (Default) / 3 DRAM Clocks / 4 DRAM Clocks /
5 DRAM Clocks
DRAM RAS# Activate to Precharge
Options: 15 DRAM Clocks (Default) / 9 DRAM Clocks / 10 DRAM Clocks /
11 DRAM Clocks / 12 DRAM Clocks / 13 DRAM Clocks /
14 DRAM Clocks
