Biostar G31D-M7 User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Pentium Dual-Core /
Celeron Dual-Core / Celeron 4xx
processor
(Maximum Watt: 65W)
Supports Hyper-Threading / Execute Disable Bit /
Enhanced Intel SpeedStep® / Int el Archit ecture-64 /
Extended Memory 64 Technology / Virtualization
Technology
FSB Support 800 / 1066 / 1333 MHz
Chipset
Intel G31
Intel ICH7
Super I/O
ITE 8712F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian " funct ion
Main
Memory
DIMM Slots x 2
Each DIMM supports 256MB / 512MB /
1GB / 2GB DDR2
Max Memory Capicity 4GB
Dual Channel Mode DDR2 memory modu le
Supports DDR2 800/667
Registered D IMM and ECC D IMM is not supported
Graphics GMA 3100 Max Shared Video Memory is 256MB
IDE Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 Bus Master Mode
supports PIO Mode 0~4
SATA 2 Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 s pecif icat ion co mp liant
LAN Realtek RTL 8102EL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
PCI slot x1 Supports PCI expansion cards
Slots
PCI Express x 16 slot x1 Supports PCI-E x16 expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
On Board
Connector
Serial port Connector (Optional) x1 Connects to RS-232 Port

Biostar G31D-M7 Specifications

General

Form Factor	Micro ATX
CPU Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	4GB
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA 3100
Video Outputs	1 x VGA
Chipset	Intel G31
Memory Standard	DDR2 667/800
Expansion Slots	1 x PCI Express x16, 2 x PCI
Audio	Realtek ALC662 6-Channel HD Audio
LAN	Realtek RTL8102EL 10/100 Mbps
USB Ports	4 x USB 2.0 (Rear)
Power Connector	24-pin ATX
