Biostar H610MH User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 12th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® H610
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200
2x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 1x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s)
1x M.2 (M Key) Socket (M2_PCIEG3_32G_ SATA):
Supports M.2 Type 2240 /2260 /2280 SSD module
Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA SSD
LAN
Intel® I219V
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio
USB
4x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 3.0 x1 Slot
1x PCIe 4.0 x16 Slot
Rear I/Os
H610MX-E
1x WIFI Antenna Port
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH-E
1x WIFI Antenna Port
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MX
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
Internal I/Os
H610MX-E & H610MH-E
4x SATA III Connector (6Gb/s)
1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi &
Bluetooth module and Intel® CNVi
2x USB 2.0 Header (each header supports 2 USB 2.0
ports)
1x USB 3.2 (Gen1) Header (each header supports 2
USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
* M.2 (E key) Wi-Fi card is not provided
H610MX & H610MH
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0
ports)
1x USB 3.2 (Gen1) Header (each header supports 2
USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
Form Factor uATX Form Factor, 208 mm x 236 mm
OS Support
Windows 10(64bit) / Windows 11(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar H610MH Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1867, 2133, 2400, 2666, 2933, 3200 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
Supported storage drive interfaces	M.2, SATA III
HDCP	Yes
DirectX version	12.0
Parallel processing technology support	-
BIOS type	UEFI
Number of SATA III connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H610
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	236 mm
Width	208 mm
