1.3 MOTHERBOARD FEATURES
H61 MG C H61 MLC
CPU
Socket 1155
Intel Core i7/i5/i3/Pentium/Celeron processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Intel Core i7/i5/i3/Pentium/Celeron processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Controller
ITE's "S mart Guardian " function
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Controller
ITE's "S mart Guardian " function
Main Memory
DIMM Slots x 2, Each DIMM supports 512MB /
1GB / 2GB / 4GB / 8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066/1333/1600 (depending
on CPU)
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2, Each DIMM supports 512MB /
1GB / 2GB / 4GB / 8GB DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066/1333/1600 (depending
on CPU)
Registered DIMM and ECC DIMM is not
supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spe cif icat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spe cif icat ion co mp liant
LAN
Realtek RTL8111E / RTL8111F
Atheros AR8151
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8105E
Atheros AR8152
10 / 100 Mb/s auto negotiation
Sound Codec
VT1708B / ALC662
5.1 channels audio out
High Definition Audio
VT1708B / ALC662
5.1 channels audio out
High Definition Audio
PCI-E Gen3x16 slot (depend ing on CPU) x1 PCI-E Gen3x16 slot (depending on C PU) x1
Slots
PCI Express Gen2 x1 Slot x2 PCI Express Gen2 x1 Slot x2
