Biostar H81MHV3 User Manual

H81MHV3/H81MDV3/H81MGV3/H81MLV3/H81MHV3L
31
Japanese
󰸞󲤡
CPU 
Intel® Core i7 / i5 / i3 / Pentium / Celeron  Socket 1150
󲙉󱡰 CPU TDP 󶁘Thermal Design Power 󲙉󱡰󲒇󳃺󵄘󶁙:95 W
*CPU  
www.biostar.com.tw󱌋󳂰
 INTEL® H81

1066/ 1333/ 1600 
2 x DDR3 DIMM   󲙉󱡰 16 GB 
󱍍 DIMM 󵚧-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 
*
www.biostar.com.tw󱌋󳂰

󰼦󱪡
INTEL® H81, AHCI 
2x SATA 6Gb/s 
2x SATA 3Gb/s 
LAN
Realtek RTL 8111G (H81MHV3 & H81MDV3 & H81MGV3)
10/ 100/ 1000 Mb/s 󱊓/󱂱 󰷕󵄖󴽣󰼪
Realtek RTL 8106E (H81MLV3 & H81MHV3L)
10/ 100 Mb/s 󱊓/󱂱 󰷕󵄖󴽣󰼪
 

ALC662
5.1 ,   
USB
2x USB 3.0  (󱻕󵀱 I/O 2)
6x USB 2.0  (󱻕󵀱 I/O 2 󱌓 󱃎󴑾󳲕󳑺4)
󲈪󱹾
1x PCIe 2.0 x1 
1x PCIe 2.0 x16 (x16)
󱻕󵀱 I/O
1x PS/2 
1x PS/2 
1x VGA 
1x DVI  (H81MDV3)
1x HDMI  (H81MHV3 & H81MHV3L)
1x LAN 
2x USB 2.0 
2x USB 3.0 
3x  
󱃎󴑾 I/O
2x SATA 6.0Gb/s 
2x SATA 3.0Gb/s 
2x USB 2.0  (󱍍2 USB 2.0 )
1x 4-Pin  
1x 24-Pin  
1x CPU  
1x   
1x   
1x   
1x  CMOS 
1x   
  UATX  190 mm x 170 mm
 OS
Windows 7/ 8/ 8.1
Biostar 󴽣󳜮 OS 󱡒󲘽󲥲󵖙

Biostar H81MHV3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
CPU Socket	LGA 1150
Memory Slots	2 x DIMM
Maximum Memory	16GB
Memory Standard	DDR3 1600/1333
Expansion Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1
Storage Interface	2 x SATA 6Gb/s, 2 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel
LAN	Realtek RTL8111G - 10/100/1000 Mbps
Video Outputs	1 x VGA, 1 x HDMI
Power Connector	24-pin ATX, 4-pin ATX 12V
USB Ports	2 x USB 3.0, 4 x USB 2.0
