Biostar I945P-A7 - 2.3 Installing System Memory

I945P-A7
11
2.3 INSTALLING SYSTEM MEMORY
DDR2_A1
DDR2_A2
DDR2_B1
DDR2_B2
Codec
C
O
M
1
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the break
on the Slot.
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
