I945P-A7
1
CHAPTER 1: INTRODUCTION
1.1 MOTHERBOARD FEATURES
A. Hardware
CPU
Supports LGA 775.
Supports Intel Pentium 4 processor up to 3.8GHz.
Supports Intel Pentium D processor.
Front Side Bus at the following frequency ranges:
533MT/s (133MHz Core Clock)
800MT/s (200MHz Core Clock)
1066MT/s (266MHz Core Clock)
Supports Hyper-Threading Technology. (HT)
Supports Execute Disable Bit Technology (XD).
Supports Enhanced Intel SpeedStep® Technology (EIST).
Supports Intel Extended Memory 64 Technology (Intel EM64T).
Chipset
North Bridge: Intel 945P.
South Bridge: Intel ICH7R (for Rev 1.0).
Intel ICH7 (for Rev 2.0).
Dimensions
ATX Form Factor: 24.4cm (W) x 29.7cm (L)
Operating System Supporting
Supports Windows 2000, and Windows XP.
Super I/O
Chip: ITE IT8712F.
Low Pin Count Interface.
Provides the most commonly used legacy Super I/O
functionality.
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
