CPU Fan Header: JCFAN1
Pin Assignment
1
Ground
2
+12V
1
JCFAN1
3
FAN RPM rate Sense
System Fan Header: JSFAN1
Pin Assignment
1
Ground
2
+12V
1
JSFAN1
3
FAN RPM rate Sense
North Bridge Fan Header: JNFAN1 (optional)
Pin Assignment
1
Ground
2
+12V
1
JNFAN1
3
FAN RPM rate Sense
DDR DIMM Modules: DDR1, DDR2
DRAM Access Time: 2.5V Unbuffered/ DDR 200 MHz (PC1600)/DDR 266 MHz
(PC2100)/ DDR 333 MHz (PC2700) Type required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)
DIMM Socket
Location
DDR Module Total Memory
Size (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
***Only for reference***
