Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
PCI-EX16
PCI2
FDD1
BAT1
Codec
DIMMA1
DIMMB1
Socket AM2+
Super I/O
PCI1
JATXPWR4
JCFA N1
JPRNT1
JATXPWR1
JUS B3
JCMOS1
JSFAN1
JPANEL1
JSPDIF_OUT1
JCDIN1
SATA1
IDE1
LAN
JAUDIOF1
JUS B4
JUS B2
SATA3
SATA4SATA2
JKBMS1
JVGA1
JUSB1
JUSBLAN1
JAUD IO1
GeForce
6150 SE/7025
nForce
430/630a
BIOS
JUSBPWR2
JUSBPWR1
JKB _P WR
JCOM1
Note: represents the 1■
st
pin.
