1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+
AMD Phenom / Phenom II / Athlon / Athlon
II / Sempron processors
(Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport and PowerNow
FSB
Support HyperTransport 1.0 Ghz
Supports up to 2 GT/s Bandwidth
Chipset
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S)
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Monitor
ITE's "Smart Guardian" funct ion
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 4GB
Each DIMM supports 256MB/512MB/
1GB/2GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not supported
Graphics
GeForce 6150 SE/nForce 430 (MCP6P M2+)
GeForce 7025/nForce 630a (N68S)
Max Shared V ideo Memory is 256MB
IDE Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 spe cif icat ion co mp liant
LAN Realtek RTL 8201CL PHY
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express x16 slot x1 Supports PCI-E x16 expansion cards
Slots
PCI slot x1 Supports PCI expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
On Board
Connector
SATA Connector x2 Each connector supports 1 SATA device
