N68S3B BIOS Manual
15
Resume On PC I PME#
When you select Enabled, a PME signal from PCI card returns the system to Full ON
state.
For this function to work, you may need a LAN add-on card which supports the
Wake on LAN function. Set the Wake on LAN (WOL) jumper on motherboard to
enable if applic able.
Options: Disabled (Default) / Enabled
Resume PCIE Wake#
Enable / Disable PCIE to generate a wake event.
Options: Disabled (Default) / Enabled
Resume On LAN (MAC)
Enable / Disable LAN (MAC) to generate a wake event.
Options: Disabled (Default) / Enabled
USB Resume from S3/S4
This item allo ws you to enable o r disabled the USB res ume from S3/S4 function.
Options: Disabled (Default) / Enabled
Resume By RTC Alarm
When “Enabled”, you can set the date and time at which the RTC (real-time clock)
alarm awakens the system from Suspend mode.
Options: Disabled (Default) / Enabled
RTC Alarm Date (Days )
You can choose which date the system will boot up.
System Time
You can choos e the system boot up time, input ho ur, minute and second to sp ecify.

Biostar N68S3B Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Maximum number of SMP processors	1
Power fan connector	Yes
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Motherboard chipset	Nvidia MCP68S
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP/Vista/7
Graphics card	GeForce 7025
Maximum graphics card memory	512 MB
Parallel processing technology support	Not supported
RAID levels	0, 1
LAN controller	Realtek RTL8201CL
Networking features	Fast Ethernet
BIOS type	-

Weight and Dimensions

Depth	170 mm
Width	235 mm
