Hyper Transport MCP68 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Hyper Transport MCP68 Configuration
MCP68(SB)to K8(CPU)Freqency [800 MHZ]
MCP68(SB)to K8(CPU)LinkWidth [16 16 ]
MCP68(SB)to K8(CPU)Freq Auto [Enabled]
MCP68(SB) to K8(CPU)
frequency selection
by CPU capability
MCP68 (SB) to K8 (CPU) Freq Auto
This option allows you to auto control MCP61 (SB) to K8 (CPU) Frequency.
Options: Enabled (Default) / Disabled
MCP68 (SB) to K8 (CPU) Frequency
This option allows you to auto control MCP61 (SB) to K8 (CPU) Frequency.
Options: 800 MHz (Default) / 200 MHz / 400 MHz / 600 MHz / 1000 MHz
(Differed by CPU)
MCP61 (SB) to K8 (CPU) LinkWidth
This option allows you to auto control MCP61 (SB) to K8 (CPU) LinkWidth.
Options: 16↓16↑ (Default) / 8↓8↑ / 4↓4↑

Biostar N68S3B Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Maximum number of SMP processors	1
Power fan connector	Yes
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Motherboard chipset	Nvidia MCP68S
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP/Vista/7
Graphics card	GeForce 7025
Maximum graphics card memory	512 MB
Parallel processing technology support	Not supported
RAID levels	0, 1
LAN controller	Realtek RTL8201CL
Networking features	Fast Ethernet
