Biostar N68S3B User Manual

N68S3B BIOS Manual
35
AMD Overclocking Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
AMD Overclocking Configuration
Custom P-States [Disabled]
Core FID [x15.5 3100MHz]
Core DID [Divided by 1]
NB FID [1600 MHz]
NB VID(Core VID) [1.3750 V]
NB DID [Divided by 1]
Performance
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
Custom P-States
This item allows you to select the P-States controlling.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM3 CPU.
Options: x8.0 1600MHz ~ x15.5 3100MHz (Differed by CPU)
Core DID
This is the Core Divider.
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
NB FID
This item allows you to select the Frequency of NB chip.
Options: 800MHz ~ 2000MHz (Differed by CPU)

Biostar N68S3B Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Maximum number of SMP processors	1
Power fan connector	Yes
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Motherboard chipset	Nvidia MCP68S
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP/Vista/7
Graphics card	GeForce 7025
Maximum graphics card memory	512 MB
Parallel processing technology support	Not supported
RAID levels	0, 1
LAN controller	Realtek RTL8201CL
Networking features	Fast Ethernet
BIOS type	-

Weight and Dimensions

Depth	170 mm
Width	235 mm
