Motherboard Manual
10
C. Dual Channel Memory installation
To trigger the Dual Channel f unction of the motherboard, the memory module
must meet the following requirements:
Install memory module of the same density in pairs, shown in the f ollowing
table.
Dual Channel Status
DDR2_A1
DDR2_A2 DDR2_B1 DDR2_B2
Enabled O X O X
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
D. FSB Supporting Table
According to the FSB frequency of the installed CPU, the motherboard could
support DDR2 533/667/800/1066 modules. Please ref er to the table below to
f ind out the proper RAM module that fits the FSB of the installed CPU.
FSB of CPU
DDR2 Module
FSB 533 FSB 800 FSB 1066 FSB1333
DDR2 533 O X O X
DDR2 667 X O O O
DDR2 800 X O O O
DDR2 1066 X X X O
(O means supported, X means not supported.)
